CJB612 Police Siren Speaker
Dimensions：14 X11. 6X5(cm) /16 X1l. 6X5(cm)
- Specification
- Dimensions
- Video
- Download Instruction Manual
- Request Quote
1.Summary
CJB612 warning Siren Speaker is novel product to satisfy new century's police demand .It is with attractive design and complete functions including kinds of warning tones with warning controller for controlling the lamp directly. It is popular in the alarm field ,such as police car ,fire engine ,traffic supervision car ,and ambulance and so on .
2.Main technical parameter
| Model | CJB612 Police Siren Speaker | ||
| Output power | 100W | 150W | 200W |
| Output impedance | 8 Ω | 8 Ω | 4Ω |
| Input voltage | DC12V-14V | ||
| Input current | 7±0. 5A(13.8VDC) | 11±0. 5A (13. 8VDC) | 14±0. 5A(13. 8VDC) |
| Working temperature | 0ºC-+55ºC | ||
| Frequency | 420Hz-1780Hz | ||
| Size of mainframe | 14 X11. 6X5(cm) | 16 X1l. 6X5(cm) | |
3.Characteristic
1).This product uses monolithic integrated circuit and software programming technology, the amplifier circuit use the highly effective magnetic core transformer.
2).the circuit element of hand controller is complete adopted imported piece part. It is extremely stable and reliable quality, the primary device mainly comes in places such as singapore , us taiwan.
4.Warning Diagram
